Assembling the Lower Handle

1. Unfold the lower handle and adjust to the desired operating position.
2. Rotate the wing knobs clockwise to tighten.

NOTE: Pay attention to the power cable before tightening the knobs to avoid getting it entangled or pressed between the lower handle and deck.

Assembling the Upper Handle

1. Align the upper handle and lower handle and secure with the wing knobs and bolts.
Rotate the wing knobs clockwise to tighten.
2. There are two possible height positions. Choose the one most suitable for you.

Assembling the Grass Collection Bag

1. Insert the handle into the slots on the grass collection bag top.
2. Fully insert the rods of the metal frame into the slots on either side of the plastic base of the grass collection bag.
3. Secure the metal support rods into the fixing position on either side of the grass collection base. Ensure the side clamping sleeves are properly fixed onto the metal support frame.

N.B. There is a hole in the bottom of the grass collection bag to hang it up if required.

Whilst we don't anticipate you having any issues with your lawn mower, here's some troubleshooting guidance if its not performing at its best.

____________________

01. Why has my mower started to vibrate?

This can happen if the steel blade has been damaged.

1. Stop the motor, disconnect the power source, and inspect the blade. If the blade is worn replace it.

2. If the blade is in good condition, check the tightness of the blade screw and re-tighten if necessary.
